SELECTION 31 colors are low metal release onglaze colors for porcelain, bone china, vitreous china and earthenware.

SELECTION 31 colors were carefully developed in lead and cadmium release, alkalic and dishwasher durability.

FIRING

Porcelain	760-8400C
Bone China	740-8200C
Vitreous China	740-8200C
Earthenware	740-8200C

SELECTION 31 colors are suitable for normal firing and fast firing.

APPLICATION
SELECTION 31 colors are suitable for screen transfer printing; direct printing, spraying, pad printing and hand painting.

MESH SIZE
Recommend mesh sizes are 180-330 mesh（71-130T）for all screen applications.

MEDIUM RATIO
Color: Medium 10:5-7
Flux : Medium 10:7-9

MISCIBILITY
Selection 31 colors can be mixed with each other in any proportions except 31602 iron red, 31301 cadmium yellow, 31302 cadmium orange, 31600 and 31601 cadmium red. Cadmium containing colors can be mixed with each other.
To obtain pastel color tone, 31210 mixing white is suitable. 31100 flux is suitable for mixing and overprinting.
Overprinting 31100 flux can improve chemical resistance and glossy of 31 series colors, but strong blue 31803 and iron red 31602 may show color deviation. 32101 flux is recommended for those two colors.

FOUR COLOR PRINTING
"Cadmium" Four Colors system　　　　　"Non-Cadmium" Four Colors system

Yellow 31301（Cadium yellow） Magenta 31944 Cyan 31845 Black 31744 Flux 31100

Yellow 31303（Cadium yellow） Magenta 31955，31944 Cyan 31845 Black 31744 Flux 31100

Yellower tone can be achieved by using above "Cadmium" four color combination.
Cadmium red/yellow can be overprinted directly over the "cadmium" four colors design.

Non-Cadmium Four color system

Yellow	31303
Magenta	31944
Cyan	31845
Black	31744, 31723
Flux	31100

Printing order
yellow --> magenta --> cyan --> black --> flux

Mesh size
Recommend mesh sizes are 300-330 mesh（120-130T）for four-color process.

Medium ratio

Yellow	Medium 10:5-7
Magenta	Medium 10:5-7
Cyan	Medium 10:5-7
Black	Medium 10:5-7
Flux	Medium 10:7-9

Lead and cadmium release
SELECTION 31 colors are measured less than 0.3mg lead/dm and 0.03mg cadmium/dm release after immersion in a 4% acetic acid solution for 24 hours at room temperature.

Acid resistance
SELECTION 31 colors show no visible attack after immersion in a 4% acetic acid solution for 24 hours at room temperature.

Alkali resistance
SELECTION 31 colors show no visible attack ofter immersion in a 0.5% calgonite solution for 24 hours at 90℃.

Dishwasher resistance
SELECTION 31 colors show no visible attack ofter they were washed over 600 times. Firing in higher temperature and overprinting Flux can improve chemical resistance.
